Conditions:
Area Class:
Driver:
Starting:
Package Size:
Weight:
50 GPM @ 186’ (11.4M3/H
@ 56 M)
Non-Hazardous
Electric Motor
Automatic 120VAC, NEMA 4X
282" X 162" X 217"
(7163mm X 4115mm X 5512)
23,625 Pounds (10,716 Kilograms)
Features
Storage Vessel: Steel, 12,600 Gallons
Each (47.7 M3 Each)
Pressure Vessel: Custom Fab. ASME VIII Bladder
Type
Piping Material: FRP (Fiberglass Reinforced Plastic)
Control: Automatic 120VAC, NEMA 4X
Pump: ANSI Centrifugal, 316 SS
Water Maker: Reverse Osmosis, 2500 GPD
Filter: Duplex Cartridge, 316 SS
Skid: Fabricated Steel with Galvanized Grating
